| Camera |
●Image Sensor: 1/2.7" Progressive Scan CMOS
●Max. Resolution: 1920 × 1080
●Min. Illumination: Color: 0.01 Lux @(F2.0, AGC ON), B/W: 0 Lux with IR
●Shutter Time: 1/3 s to 1/100, 000 s
●Day & Night: IR cut filter
●Angle Adjustment: Pan: 0° to 360°, tilt: 0° to 180°, rotate: 0° to 360° |
| Lens |
●Focal Length & FOV:
○2.8 mm, horizontal FOV 112.1°, vertical FOV 60.0°, diagonal FOV 132.2°
○4 mm, horizontal FOV 90.2°, vertical FOV 48.6°, diagonal FOV 107.6°
●Lens Mount: M12
●Iris Type: Fixed
●Aperture: F2.0 |
| Image Parameters |
●Image Settings: Saturation, brightness, contrast, sharpness, AGC, white balance adjustable by client software or web browser.
●Day/Night Switch: Day, Night, Auto, Schedule
●Wide Dynamic Range (WDR): Digital WDR
●SNR: ≥ 52 dB
●Image Enhancement: BLC, 3D DNR |
| Illuminator |
●Supplement Light Type: IR
●Supplement Light Range: Up to 30 m
●Smart Supplement Light: Yes
●IR Wavelength: 850 nm |
| Video |
●Main Stream:
○50 Hz: 25 fps (1920 × 1080, 1280 × 720)
○60 Hz: 30 fps (1920 × 1080, 1280 × 720)
●Sub-Stream:
○50 Hz: 25 fps (640 × 480, 640 × 360)
○60 Hz: 30 fps (640 × 480, 640 × 360)
●Video Compression:
○Main Stream: H.265/H.264/H.264+/H.265+
○Sub-Stream: H.265/H.264/MJPEG
●Video Bit Rate: 32 Kbps to 8 Mbps
●H.264 Type: Baseline Profile/Main Profile/High Profile
●H.265 Type: Main Profile
●Region Of Interest (ROI): 1 fixed region for main stream |
| Network |
●Protocols: TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, NTP, UPnP™, SMTP, IGMP, 802.1X, QoS, IPv6, Bonjour, IPv4, UDP, SSL/TLS
●Simultaneous Live View: Up to 6 channels
●API: Open Network Video Interface, ISAPI
●User/Host: Up to 32 users. 3 levels: administrator, operator and user
●Client: iVMS-4200, Hik-Connect
●Web Browser
○Plug-in required live view: IE 10+
○Plug-in free live view: Chrome 57.0+, Firefox 52.0+
○Local service: Chrome 57.0+, Firefox 52.0+ |
| Event |
●Basic Event: Motion detection, video tampering alarm, exception
●Linkage: Upload to FTP, notify surveillance center, send email |
| Interface |
●Ethernet Interface: 1 RJ45 10 M/100 M self-adaptive Ethernet port |
| General |
●Power:
○12 VDC ± 25%, 0.4 A, max. 5 W, Ø5.5 mm coaxial power plug
○PoE: 802.3af, Class 3, 36 V to 57 V, 0.2 A to 0.15 A, max. 6.5 W
●Dimension: 177.6 mm × 66.2 mm × 67.8 mm (7.0" × 2.6" × 2.7")
●Package Dimension: 216 mm × 121 mm × 118 mm (8.5" × 4.8" × 4.6")
●Weight: Approx. 270 g (0.6 lb.)
●With Package Weight: Approx. 490 g (1.1 lb.)
●Storage Conditions: -30 °C to 60 °C (-22 °F to 140 °F). Humidity: 95% or less (non-condensing)
●Startup And Operating Conditions: -30 °C to 60 °C (-22 °F to 140 °F). Humidity: 95% or less (non-condensing)
●Language: English, Ukrainian
●General Function: Anti-flicker, heartbeat, mirror, password protection, privacy mask, watermark, IP address filter |
| Approval |
●EMC: FCC SDoC (47 CFR Part 15, Subpart B); CE-EMC (EN 55032: 2015, EN 61000-3-2: 2014, EN 61000-3-3: 2013, EN 50130-4: 2011 +A1: 2014); RCM (AS/NZS CISPR 32: 2015); IC VoC (ICES-003: Issue 6, 2016); KC (KN 32: 2015, KN 35: 2015)
●Safety: UL (UL 60950-1); CB (IEC 60950-1:2005 + Am 1:2009 + Am 2:2013, IEC 62368-1:2014); CE-LVD (EN 60950-1:2005 + Am 1:2009 + Am 2:2013, IEC 62368-1:2014); BIS (IS 13252(Part 1):2010+A1:2013+A2:2015)
●Environment: CE-RoHS (2011/65/EU); WEEE (2012/19/EU); Reach (Regulation (EC) No 1907/2006)
●Protection: IP67 (IEC 60529-2013) |
