| Camera |
●Image Sensor: 1/1.8" Progressive Scan CMOS
●Max. Resolution: 2688 × 1520
●Min. Illumination: Color: 0.0005 Lux @ (F1.0, AGC ON), 0 Lux with white light
●Shutter Time: 1/3 s to 1/100,000 s
●Angle Adjustment: Pan: 0° to 360°, tilt: 0° to 90°, rotate: 0° to 360° |
| Lens |
●Focal Length & FOV:
○2.8 mm, horizontal FOV 111.9°, vertical FOV 60.5°, diagonal FOV 133.6°
○4 mm, horizontal FOV 95.2°, vertical FOV 50.6°, diagonal FOV 114.7°
○6 mm, horizontal FOV 58.4°, vertical FOV 31°, diagonal FOV 68.7°
●Lens Mount: M16
●Iris Type: Fixed
●Aperture: F1.0
●Depth Of Field:
○2.8 mm: 3.1 m to ∞
○4 mm: 5.4 m to ∞
○6 mm: 12.1 m to ∞ |
| DORI |
●DORI:
○2.8 mm, D: 58.2 m, O: 23.1 m, R: 11.6 m, I: 5.8 m
○4 mm, D: 77 m, O: 30.5 m, R: 15.4 m, I: 7.7 m
○6 mm, D: 115.6 m, O: 45.9 m, R: 23.1 m, I: 11.6 m |
| Image Parameters |
●Image Parameters Switch: Yes
●Image Settings: Rotate mode, saturation, brightness, contrast, sharpness, gain, white balance adjustable by client software or web browser
●Day/Night Switch: Auto, Schedule
●Wide Dynamic Range (WDR): 130 dB
●SNR: ≥ 52 dB
●Image Enhancement: BLC, HLC, 3D DNR |
| Illuminator |
●Supplement Light Type: White Light
●Supplement Light Range: Up to 40 m
●Smart Supplement Light: Yes |
| Video |
●Main Stream:
○50 Hz: 25 fps (2688 × 1520, 1920 × 1080, 1280 × 720)
○60 Hz: 30 fps (2688 × 1520, 1920 × 1080, 1280 × 720)
●Sub-Stream:
○50 Hz: 25 fps (1280 × 720, 640 × 480, 640 × 360)
○60 Hz: 30 fps (1280 × 720, 640 × 480, 640 × 360)
●Third Stream:
○50 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360)
○60 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360)
*Third stream is supported under certain settings.
●Video Compression:
○Main stream: H.265/H.264/H.265+/H.264+
○Sub-stream: H.265/H.264/MJPEG
○Third stream: H.265/H.264
*Third stream is supported under certain settings.
●Video Bit Rate: 32 Kbps to 8 Mbps
●H.264 Type: Baseline Profile/Main Profile/High Profile
●H.265 Type: Main Profile
●Bit Rate Control: CBR/VBR
●Scalable Video Coding (SVC): H.265 and H.264 encoding
●Region Of Interest (ROI): 1 fixed region for main stream and sub-stream |
| Audio |
●Audio Compression: G.711ulaw/G.711alaw/G.722.1/G.726/MP2L2/PCM/MP3/AAC-LC
●Audio Bit Rate: 64 Kbps (G.711ulaw/G.711alaw)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 to 192 Kbps (MP2L2)/8 to 320 Kbps (MP3)/16 to 64 Kbps (AAC-LC)
●Audio Sampling Rate: 8 kHz/16 kHz/32 kHz/44.1 kHz/48 kHz
●Environment Noise Filtering: Yes |
| Network |
●Protocols: TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, NTP, UPnP, SMTP, IGMP, 802.1X, QoS, IPv4, IPv6, UDP, Bonjour, SSL/TLS, PPPoE, SNMP, ARP, WebSocket, WebSockets
●Simultaneous Live View: Up to 6 channels
●API: Open Network Video Interface (PROFILE S, PROFILE G, PROFILE T), ISAPI, SDK
●User/Host: Up to 32 users. 3 user levels: administrator, operator and user
●Security: Password protection, complicated password, HTTPS encryption, IP address filter, Security Audit Log, basic and digest authentication for HTTP/HTTPS, TLS 1.1/1.2, WSSE and digest authentication for Open Network Video Interface
●Network Storage:
○NAS (NFS, SMB/CIFS), auto network replenishment (ANR), microSD/microSDHC/microSDXC card (512 GB) local storage
○Together with high-end Hikvision memory card, memory card encryption and health detection are supported
●Client: iVMS-4200, Hik-Connect, Hik-Central
●Web Browser:
○Plug-in required live view: IE 10, IE 11
○Plug-in free live view: Chrome 57.0+, Firefox 52.0+, Edge 89+
○Local service: Chrome 57.0+, Firefox 52.0+, Edge 89+ |
| Event |
●Basic Event: Motion detection (human and vehicle targets classification), video tampering alarm, exception
●Smart Event:
○Line crossing detection, intrusion detection, region entrance detection, region exiting detection (support alarm triggering by specified target types (human and vehicle))
○Scene change detection
●Linkage: Upload to NAS/memory card/FTP, notify surveillance center, trigger recording, trigger capture, send email, strobe light, audible warning, trigger alarm output |
| Deep Learning Function |
●Face Capture: Yes |
| Interface |
●Ethernet Interface: 1 RJ45 10 M/100 M self-adaptive Ethernet port
●On-Board Storage: Built-in memory card slot, support microSD/microSDHC/microSDXC card, up to 512 GB
●Built-In Microphone: Yes
●Built-In Speaker: 1.2 W, 10 cm: 95 dB
●Alarm: Visual alarm
●Reset Key: Yes |
| General |
●Power:
○12 VDC, 0.5 A, max. 6 W, Ø5.5 mm coaxial power plug
○PoE: 802.3af, Class 3, 36 V to 57 V, 0.25 A to 0.15 A , max. 7.5 W
●Dimension: Ø74.4 mm × 179.2 mm (Ø2.9" × 7.1")
●Package Dimension: 234 mm × 120 mm × 117 mm (9.2" × 4.7" × 4.6")
●Weight: Approx. 510 g (1.1 lb.)
●With Package Weight: Approx. 760 g (1.7 lb.)
●Storage Conditions: -30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)
●Startup And Operating Conditions: -30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)
●Language: 33 languages: English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil), Ukrainian
●General Function: Anti-flicker, heartbeat, mirror, privacy mask, flash log, password reset via email, pixel counter |
| Approval |
●EMC:
○FCC SDoC: 47 CFR Part 15, Subpart B;
○CE-EMC: EN 55032: 2015, EN 61000-3-2: 2014, EN 61000-3-3: 2013, EN 50130-4: 2011 +A1: 2014;
○RCM: AS/NZS CISPR 32: 2015;
○IC VoC: ICES-003: Issue 6, 2016;
○KC: KN 32: 2015, KN 35: 2015
●Safety:
○UL: UL 60950-1;
○CB: IEC 60950-1:2005 + Am 1:2009 + Am 2:2013, IEC 62368-1:2014;
○CE-LVD: EN 60950-1:2005 + Am 1:2009 + Am 2:2013, IEC 62368-1:2014;
○LOA: IEC/EN 60950-1
●Environment:
○CE-RoHS: 2011/65/EU;
○WEEE: 2012/19/EU;
○Reach: Regulation (EC) No 1907/2006
●Protection: IP67: IEC 60529-2013 |
