| Camera |
●Image Sensor: 1/1.2" Progressive Scan CMOS
●Max. Resolution: 3840 × 2160
●Min. Illumination: Color: 0.0005 Lux @ (F1.0, AGC ON), 0 Lux with Light
●Shutter Time: 1/3 s to 1/100,000 s
●Angle Adjustment: Pan: 0° to 360°, tilt: 0° to 90°, rotate: 0° to 360° |
| Lens |
●Lens Type: Fixed focal lens, 2.8, 4, and 6 mm optional
●Focal Length & FOV
○2.8 mm: horizontal FOV102°, vertical FOV 52°, diagonal FOV 124°
○4 mm: horizontal FOV 88°, vertical FOV 47°, diagonal FOV 104°
○6 mm: horizontal FOV 54°, vertical FOV 30°, diagonal FOV 62°
●Iris Type: Fixed
●Aperture: F1.0
●Depth Of Field:
○2.8 mm: 4.5 m to ∞
○4 mm: 7 m to ∞
○6 mm: 13 m to ∞ |
| DORI |
●DORI
○2.8 mm, D: 96 m, O: 38 m, R: 19 m, I: 10 m
○4 mm, D: 102 m, O: 41 m, R: 21 m, I: 11 m
○6 mm, D: 167 m, O: 66 m, R: 33 m, I: 16 m |
| Image Parameters |
●Image Parameters Switch: Yes
●Image Settings: Rotate, mirror, privacy mask, saturation, brightness, contrast, sharpness, gain, white balance adjustable by client software or web browser
●Day/Night Switch: Day, Night, Auto, Schedule
●Wide Dynamic Range (WDR): 130 dB
●SNR: ≥ 52 dB
●Image Enhancement: BLC, HLC, 3D DNR |
| Illuminator |
●Supplement Light Type: White light
●Supplement Light Range: 40 m
●Smart Supplement Light: Yes |
| Video |
●Main Stream:
○50 Hz:
25 fps (3840 × 2160, 3200 × 1800 , 2688 × 1520, 1920 × 1080, 1280 × 720)
○60 Hz:
24 fps (3840 × 2160)
30 fps (3200 x 1800 , 2688 × 1520, 1920 × 1080, 1280 × 720)
●Sub-Stream
○50 Hz: 25 fps (640 × 480, 640 × 360)
○60 Hz: 30 fps (640 × 480, 640 × 360)
●Third Stream
○50 Hz: 10 fps (1920 x 1080 , 1280 × 720, 640 × 480, 640 × 360)
○60 Hz: 10 fps (1920 x 1080 , 1280 × 720, 640 × 480, 640 × 360)
●Video Compression
○Main stream: H.265/H.264/H.264+/H.265+
○Sub-stream: H.265/H.264/MJPEG
○Third stream: H.265/H.264
●Video Bit Rate: 32 Kbps to 16 Mbps
●H.264 Type: Baseline Profile/Main Profile/High Profile
●H.265 Type: Main Profile
●Bit Rate Control: CBR/VBR
●Scalable Video Coding (SVC): H.264 and H.265 encoding
●Region Of Interest (ROI): 1 fixed region for main stream and sub-stream |
| Audio |
●Audio Compression: -U: G.711ulaw/G.711alaw/G.722.1/G.726/MP2L2/PCM/MP3/AAC
●Audio Bit Rate: -U: 64 Kbps (G.711 ulaw)/64 Kbps(G.711 alaw)/16 Kbps(G.722.1)/16 Kbps(G.726)/32 to 192 Kbps(MP2L2)/8 to 320 Kbps(MP3)/16 to 64Kbps(AAC)
●Audio Sampling Rate: -U: 8 kHz/16 kHz/32 kHz/44.1 kHz/48 kHz
●Environment Noise Filtering: -U: Yes |
| Network |
●Protocols: TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, NTP, UPnP, SMTP, IGMP, 802.1X, QoS, IPv4, IPv6, UDP, Bonjour, SSL/TLS, PPPoE, SNMP
●Simultaneous Live View: Up to 6 channels
●API: Open Network Video Interface (Profile S, Profile G, Profile T), ISAPI, SDK
●User/Host: Up to 32 users. 3 user levels: administrator, operator and user
●Security: Password protection, complicated password, HTTPS encryption, IP address filter, Security Audit Log, basic and digest authentication for HTTP/HTTPS, TLS 1.1/1.2, WSSE and digest authentication for Open Network Video Interface
●Network Storage: NAS (NFS, SMB/CIFS), auto network replenishment (ANR)
●Client: iVMS-4200, Hik-Connect, Hik-Central
●Web Browser:
○Plug-in required live view: IE 10, IE 11
○Plug-in free live view : Chrome 57.0+, Firefox 52.0+
○Local service: Chrome 57.0+, Firefox 52.0+ |
| Event |
●Basic Event: Motion detection (human and vehicle targets classification), video tampering alarm, exception (network disconnected, IP address conflict, illegal login, HDD full, HDD error)
●Smart Event:
○Line crossing, intrusion, region entrance, region exiting (support alarm triggering by specified target types (human and vehicle))
○Scene change detection
●Linkage
Upload to FTP/memory card/NAS, notify surveillance center, trigger record, trigger capture, send email |
| Deep Learning Function |
●Face Capture: Yes |
| Interface |
●Ethernet Interface: 1 RJ45 10 M/100 M self-adaptive Ethernet port
●On-Board Storage: Built-in memory card slot, support microSD/microSDHC/microSDXC/TF card, up to 256 GB
●Built-In Microphone: -U: Yes
●Reset Key: Yes |
| General |
●Power
○12 VDC ± 25%, 0.5 A, max. 6 W, Ø5.5 mm coaxial power plug, reverse polarity protection
○PoE: (802.3af, Class 3, 36 V to 57 V), 0.25 A to 0.15 A, max. 7.5 W
●Dimension: 78.8 × 78.6 × 215.2 mm (3.1" × 3.1" × 8.5")
●Package Dimension: 315 × 137 × 141 mm (12.4" × 5.4" × 5.6")
●Weight: Approx. 850 g (1.9 lb.)
●With Package Weight: Approx. 1270 g (2.8 lb.)
●Storage Conditions: -30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)
●Startup And Operating Conditions: -30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing)
●Language: 33 languages:English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil), Ukrainian
●General Function: Anti-flicker, heartbeat, password reset via e-mail, pixel counter |
| Approval |
●EMC:
○FCC (47 CFR Part 15, Subpart B);
○CE-EMC (EN 55032: 2015, EN 61000-3-2:2019, EN 61000-3-3:2013+A1:2019, EN 50130-4: 2011 +A1: 2014);
○RCM (AS/NZS CISPR 32: 2015);
○IC (ICES-003: Issue 7)
●Safety:
○UL (UL 62368-1);
○CB (IEC 62368-1:2014+A11)
○CE-LVD (EN 62368-1:2014/A11:2017)
●Environment:
○CE-RoHS (2011/65/EU);
○WEEE (2012/19/EU);
○Reach (Regulation (EC) No 1907/2006)
●Protection: IP67 (IEC 60529-2013) |
