Camera |
●Image Sensor: 1/2.8" progressive scan CMOS ●Min. Illumination: 0 Lux with IR,color: 0.005Lux @ (F1.6,AGC ON); B/W: 0.001Lux @ (F1.6,AGC ON) ●Shutter Speed: 1/1s-1/30000s ●Slow Shutter: yes ●Focus: semi-auto;manual;auto ●Day & Night :ICR ●Day/Night Switch: day, night, auto, scheduled-switch ●BLC: yes ●WDR: 120 dB WDR ●HLC: yes ●3D DNR: yes ●Defog: yes ●EIS: yes ●Regional Exposure: yes ●Regional Focus: yes ●Image Settings: brightness;contrast;sharpness;saturation ●White Balance: auto;ATW;sodium lamp;indoor;fluorescent lamp;outdoor;MWB;Locked WB;Locked WB ●Digital Zoom: 16x ●Optical Zoom: 25x ●Privacy Mask: up to 24 masks;polygon region ;mosaic mask ;mask color configurable ●SNR: >52dB |
Lens |
●Focal Length: 4.8 mm to 120 mm, 25× Optical ●Zoom Speed: approx. 3.6 s ●FOV: ○Horizontal field of view: 55° to 2.4° (wide-tele), ○Vertical field of view: 33° to 1.4° (wide-tele), ○Diagonal field of view: 61.5° to 2.8° (wide-tele) ●Aperture: F1.6 |
Illuminator |
●IR Distance: 100 m |
PTZ |
●Movement Range (Pan) :360° ●Movement Range (Tilt) :-15° to 90° (auto flip) ●Pan Speed :pan speed: configurable from 0.1° to 80°/s; preset speed: 80°/s ●Tilt Speed: tilt speed: configurable from 0.1° to 80°/s, preset speed 80°/s ●Proportional Zoom: yes ●Presets: 300 ●Patrol Scan: 8 patrols, up to 32 presets for each patrol ●Pattern Scan: 4 pattern scans ●Power-Off Memory: yes ●Park Action: preset;pattern scan;patrol scan;auto scan;tilt scan;random scan;frame scan;panorama scan ●3D Positioning: yes ●PTZ Status Display: yes ●Preset Freezing: yes ●Scheduled Task: preset;pattern scan;patrol scan;auto scan;panorama scan;random scan;tilt scan;frame scan;dome reboot;dome adjust;aux output |
Video |
●Max. Resolution: 2560 × 1440 ●Stream Type: main stream;sub-stream;third stream ●Main Stream: ○50Hz:25fps (2560×1440,1920×1080,1280×960,1280×720) ○60Hz: 30fps(2560×1440,1920×1080,1280×960,1280×720) ●Sub-Stream: ○50Hz: 25fps (704 × 576, 640 × 480, 352 × 288) ○60Hz: 30fps (704 × 480, 640 × 480, 352 × 240) ●Third Stream: ○50Hz: 25fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 576, 640 × 480, 352 × 288) ○60Hz: 30fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 480, 640 × 480, 352 × 240) ●Video Compression :H.265;H.264;MJPEG ●Video Bit Rate :32kbps to 16384kbps ●H.264 Type :Baseline Profile;Main Profile;High Profile;baseline profile;main profile;high profile ●H.265 Type :Main Profile;main profile ●H.264+ :yes ●H.265+ :yes ●SVC :yes ●ROI: dynamic face tracking;fixed region;main stream, sub-stream and third stream respectively support eight fixed areas |
Audio |
●Audio Compression :G.711alaw;G.711ulaw;G.722.1;G.726;MP2L2;PCM ●Audio Bit Rate :MP2L2: 32 kbps, 40 kbps, 48 kbps, 56 kbps, 64 kbps, 80 kbps, 96 kbps, 112 kbps, 128 kbps, 144 kbps, 160 kbps, 192 kbps;MP2L2: 32 kbps, 40 kbps, 48 kbps, 56 kbps, 64 kbps, 80 kbps, 96 kbps, 112 kbps, 128 kbps, 144 kbps, 160 kbps;192kbps ●Audio Sampling Rate: MP2L2: 16 kHz, 32 kHz, 48 kHz, PCM: 8 kHz, 16 kHz, 32 kHz, 48 kHz ●Environment Noise Filtering: yes |
Smart Features |
●Face Capture: yes ●Basic Event :audio exception;motion detection;video tampering alarm;exception ●Smart Event :intrusion detection;line crossing detection;region entrance detection;region exiting detection;unattended baggage detection;object removal detection ●Smart Record :ANR;Dual-VCA ●Alarm Linkage: preset;patrol scan;pattern scan;memory card video recording;alarm output;sending email;notify surveillance center; upload to FTP |
Network |
●Network Storage: NAS (NFS, SMB/ CIFS);ANR ●Protocols: IPv4/IPv6;HTTP;HTTPS;802.1x;Qos;FTP;SMTP;UPnP;SNMP;DNS;DDNS;NTP;RTSP;RTCP;RTP;TCP/IP;UDP;IGMP;ICMP;DHCP;PPPoE;Bonjour ●API: ISAPI;Hikvision SDK;ONVIF (Profile S, Profile G, Profile T);ISUP;Hik-Connect ●Simultaneous Live View: 20 ●User/Host: 32 ●Smooth Streaming: yes ●Security Measures: Authenticated username and password;MAC address binding;HTTPS encryption;802.1X authenticated access;IP address filter ●Client: iVMS-4200;Hik-Connect ●Web Browser: IE 8 to 11, Chrome 57+, Firefox 52+, Safari 12+ |
Interface |
●Communication Interface: 1 RJ45 10 M/100 M Ethernet interface; PoE (802.3at);RJ45, self-adaptive 10M/100M Ethernet port ●On-Board Storage: support microSD/microSDHC/microSDXC cards;up to 256 GB ●Alarm Input: 1 alarm input ●Alarm Output: 1 alarm output ●Audio Input: 1 audio input, 2.0 to 2.4Vp-p, 1k Ohm±10% ●Audio Output: 1 audio output, line level, impedance: 600 Ω |
General |
●Power: 12 VDC,PoE(802.3at) ●Power Consumption And Current: Max. 24 W, including max. 9 W for supplement light ●Operating Conditions: humidity lower than 90%RH ;temperature: -30℃ to 65℃ (-22°F to 149°F) ●Reset: yes ●Material: ADC 12, PC, PC+10% GF ●Dimensions: Φ 164.5 mm × 290 mm (Φ 6.48" × 11.42") ●Weight: Approx. 2 kg (4.41 lb) |
Approval |
●Protection: ○IP66; ○4000V Lightning Protection, Surge Protection and Voltage Transient Protection |
